Free Cutting Stainless Steel Tube Pipe 403 420 410 440a For Construction Machine

The 403 Series offers heat resistance and a scaling temperature of about 1300°F. It is a corrosion and heat resistant 12% Cr martensitic stainless steel. This alloy offers a wide range of mechanical properties that are obtainable by appropriate heat treatments. It is easily hardened by oil, fan or air cooling and may be tempered at temperatures of up to 1350°F (732°C) to improve fracture toughness. Oil or fan cooling is required in thicker sections.

Alloy 410 is the basic, general purpose martensitic stainless steel that is used for highly stressed parts and provides good corrosion resistance plus high strength and hardness. Alloy 410 contains a minimum of 11.5% chromium which is just sufficient enough to demonstrate corrosion resistance properties in mild atmospheres, steam, and many mild chemical environments. It is a general purpose grade that is often supplied in the hardened but still machineable condition for applications where high strength and moderate heat and corrosion resistance are required. Alloy 410 displays maximum corrosion resistance when it’s been hardened, tempered, and then polished.

Alloy 420 is a hardenable, martensitic stainless steel that is a modification of Alloy 410. Similar to 410, it contains a minimum of 12% chromium, just sufficient enough to give corrosion resistant properties. Alloy 420 has higher carbon content than Alloy 410 which is designed to optimize strength and hardness characteristics. It has good ductility it the annealed condition but is capable of being hardened to a minimum Rockwell hardness of 50 HRC, the highest hardness of the 12% chromium grades. Due to its hardening properties, Alloy 420 is not often welded, although it is possible. Martensitic stainless steels are designed for high hardness and sometimes other properties are to some degree compromised.

Type 440A is a corrosion resistant martensitic stainless steel containing approximately 17% chromium offering a wide range of mechanical properties through heat treatment. This grade offers the superior wear resistance of high carbon steel with the corrosion resistance of a stainless steel. The optimum corrosion and hardness are obtained in the hardened and hardened and tempered condition. Type 440A is used for cutlery applications as well as dental and surgical instruments and is magnetic in both the annealed and heat-treated conditions.
